Shock and anti-cavitation valve
The valve limits pressure from port A or B vis-à-vis pressure applied to T to the selected value.
Adjustable parameters
| Designation | Range | Default value |
|---|---|---|
| Opening pressure | 0 ... 40 MPa | 3 |
| Pressure regulation range | 0.01 ... 10 MPa | 3.8 |
| Hydraulic resistance | 1e-6 ... 1000 bar.min2/l2 | 0.08 |
| Designation | Range | Default value |
|---|---|---|
| Opening pressure | 0 ... 40 MPa | 3 |
| Pressure regulation range | 0.01 ... 10 MPa | 3.8 |
| Hydraulic resistance | 1e-6 ... 1000 bar.min2/l2 | 0.08 |
